| Specification | Details |
|---|---|
| Model Number | STQ5310XXY14 |
| Vehicle Type | Box Truck |
| Drive Type | 8×4 |
| Wheelbase | 1850 + 4500 + 1350 mm |
| Container Length Level | 9.6 meters |
| Engine | Yuchai YC6L290-42 |
| Transmission | Fast 9JS119 |
| Rear Axle Ratio | 3.25 |
| Vehicle Length | 11.99 meters |
| Vehicle Width | 2.55 meters |
| Vehicle Height | 3.95 meters |
| Front Track | 2040 / 2040 mm |
| Rear Track | 1860 / 1860 mm |
| Curb Weight | 11.78 tons |
| Rated Load Capacity | 18.925 tons |
| Gross Vehicle Weight | 30.9 tons |
| Maximum Speed | 88 km/h |
| Tonnage Class | Heavy Truck |
| Approach Angle | 25° |
| Departure Angle | 26° |
| Energy Type | Diesel |
| Engine Brand | Yuchai |
| Engine Model | Yuchai YC6L290-42 |
| Engine Description | Yuchai 8.4L |
| Number of Cylinders | 6 |
| Cylinder Arrangement | Inline |
| Displacement | 8.424 L |
| Emission Standard | National IV |
| Maximum Power | 213 kW |
| Maximum Horsepower | 290 hp |
| Maximum Torque | 1150 Nm |
Automotion Global – Authorized Exporter for Tri-Ring
-
1-Year Warranty included for peace of mind.
-
1-Year Free Spare Parts provided with the vehicle.
-
Lifetime Parts Support ensuring long-term reliability and easy maintenance.
-
Automotion Global is the Authorized Exporter for Tri-Ring, providing trusted international supply and after-sales support.
