| Specification | Details |
|---|---|
| Vehicle Model | STQ5048XXYNBEV |
| Drive Type | 4×2 |
| Gross Vehicle Weight | 4,495 kg |
| Curb Weight | 3,040 kg |
| Overall Dimensions (L × W × H) | 5,995 × 2,200 × 3,150 mm |
| Wheelbase | 3,360 mm |
| Maximum Speed | 88 km/h |
| Maximum Gradeability | 23% |
| Drive Motor Manufacturer | Yuchai |
| Rated / Peak Power | 60 / 115 kW |
| Power Battery | CATL 100.46 kWh |
| Battery Layout | Bottom Mounted |
| Brake Type | Hydraulic / Air Brakes with ABS Anti-Lock Braking System |
| Service Braking System | 82° Hydraulic Brakes, 100° Air Brakes |
| Parking Brake System | Manual Cable / Air Brake |
| Parking Control | Hand Brake Control |
| System Voltage | 24 V |
| Auxiliary Battery | 75Ah Dual Battery |
| Cargo Box Size | 4,150 mm |
| Base Plate Thickness | 2 mm |
Automotion Global – Authorized Exporter for Tri-Ring
-
3-Year Battery Warranty ensuring long-term performance and reliability.
-
1-Year Vehicle Warranty included for peace of mind.
-
1-Year Free Spare Parts provided with the vehicle.
-
Lifetime Parts Support ensuring long-term reliability and easy maintenance.
-
Automotion Global is the Authorized Exporter for Tri-Ring, providing trusted international supply and after-sales support.
