| Specification | Details |
|---|---|
| Model Number | STQ3311L16Y6B6 |
| Drive Type | 8×4 |
| Wheelbase | 1850 + 4300 + 1350 mm |
| Transmission | Fast, 12 gears |
| Rear Axle Ratio | 5.92 |
| Vehicle Length | 10.04 meters |
| Vehicle Width | 2.5 meters |
| Vehicle Height | 3 meters |
| Front Track | 1986 / 1986 mm |
| Rear Track | 1750 / 1750 mm |
| Curb Weight | 15.2 tons |
| Rated Load Capacity | 15.605 tons |
| Gross Vehicle Weight | 31 tons |
| Tonnage Class | Heavy Truck |
| Approach Angle | 15° |
| Departure Angle | 16° |
| Energy Type | Diesel |
| Engine Brand | Weichai |
| Engine Model | WP8.350E61 |
| Number of Cylinders | 6 |
| Fuel Type | Diesel |
| Displacement | 7.8 L |
| Emission Standard | National VI |
| Maximum Horsepower | 350 hp |
| Maximum Power | 257 kW |
| Maximum Torque | 1400 Nm |
Automotion Global – Authorized Exporter for Tri-Ring
-
1-Year Warranty included for peace of mind.
-
1-Year Free Spare Parts provided with the vehicle.
-
Lifetime Parts Support ensuring long-term reliability and easy maintenance.
-
Automotion Global is the Authorized Exporter for Tri-Ring, providing trusted international supply and after-sales support.
