| Specification | Details |
|---|---|
| Model Number | LMX5040TQZST6 |
| Drive Type | 4×2 |
| Gross Vehicle Weight | 4,495 kg |
| Curb Weight | 2,865 kg |
| Overall Dimensions (L × W × H) | 5,995 × 2,300 × 2,180 mm |
| Wheelbase | 3,600 / 3,360 mm |
| Maximum Speed | 105 km/h |
| Maximum Gradeability | 30% |
| Emission Standard | Euro III |
| Engine Manufacturer | Guangxi Yuchai |
| Displacement | 2.3 – 2.5 L |
| Rated Power | 103 – 130 kW |
| Flatbed Size | 5,600 × 2,300 mm |
| Minimum Slope of Flat Plate | 10° |
| Maximum Load Capacity | 1,500 kg |
| Number of Winches | 1 |
| Rated Traction Weight | 1,500 kg |
| Wire Rope Length | 15 m |
| Winch Rope Speed | 8 m/min |
Automotion Global – Authorized Exporter for Tri-Ring
-
1-Year Warranty included for peace of mind.
-
1-Year Free Spare Parts provided with the vehicle.
-
Lifetime Parts Support ensuring long-term reliability and easy maintenance.
-
Automotion Global is the Authorized Exporter for Tri-Ring, providing trusted international supply and after-sales support.
